Product Introduction
Technical Specifications
(I) Filtration Precision
The filtration precision range is relatively wide, ranging from dozens of micrometers to hundreds of micrometers. Common specifications include 50 micrometers, 100 micrometers, and 200 micrometers. Users can choose products with appropriate filtration precision according to the actual filtration needs, such as the type of the medium to be processed and the particle size of impurities.
(II) Flow Rate Range
It can adapt to different flow rate requirements, ranging from a few cubic meters per hour to thousands of cubic meters per hour, covering many small, medium and large-scale filtration application scenarios, and can match different scales of industrial production lines or civil water supply and drainage systems.
(III) Working Pressure
Generally, the working pressure it can withstand is between 0.1MPa and 1.6MPa. Some high-pressure equipment can even reach higher pressure values, enabling it to be applied to pipeline systems of different pressure levels and ensuring stable and reliable operation under corresponding pressure conditions.
(IV) Cleaning Cycle
The cleaning cycle can be flexibly set according to the actual situation, ranging from a few minutes to several hours or even days. It is mainly determined by factors such as the amount of impurities in the filtering medium and the blockage of the filter screen. By reasonably setting the cleaning cycle, both the filtering effect can be ensured and the energy waste and equipment wear caused by excessive cleaning can be avoided.
Working Process
When the fluid (such as water, oil, etc.) containing impurities enters the automatic self-cleaning filter, it will first be evenly directed to the filter screen under the guidance of the internal flow guide device. When the fluid passes through the filter screen, the impurity particles are intercepted on the surface of the filter screen because they cannot pass through the meshes of the filter screen, while the clean fluid smoothly passes through the filter screen and is discharged from the outlet of the filter, realizing the initial filtering process.
As the filtration continues, the impurities on the surface of the filter screen keep accumulating. When the set degree of blockage or time interval is reached, the intelligent control system will automatically start the cleaning device. The cleaning device usually removes the impurities on the surface of the filter screen through methods such as suction, brush cleaning, and high-pressure backwashing. The removed impurities will be discharged out of the filter along the sewage pipeline. Subsequently, the filter can continue to carry out efficient filtration work, and this cycle repeats to ensure that the fluid is continuously purified.
Product Features
(I) High Degree of Automation
The biggest advantage of the automatic self-cleaning filter lies in its high degree of automation. It does not require frequent manual intervention and can automatically complete a series of operations such as filtering, detecting the blockage of the filter screen and cleaning according to the preset parameters, which greatly saves labor costs and also avoids problems such as poor filtering effect caused by human negligence.
(II) High-Efficiency Filtration and Stable Operation
With the help of high-precision filter screens, it can effectively intercept impurities of different particle sizes, and has a high filtration efficiency. Moreover, the overall structure of the equipment is stable, and the various components are closely coordinated. During the long-term operation, as long as the maintenance is carried out in accordance with the specifications, it can continuously and stably filter the fluid, ensuring the normal operation of downstream equipment or usage links.
(III) Good Cleaning Effect
It adopts a combination of multiple advanced cleaning methods. Whether it is impurities with strong adsorption or stubborn dirt attached, they can be effectively removed from the surface of the filter screen, ensuring the permeability of the filter screen, maintaining good filtering performance, extending the service life of the filter screen, and reducing the cost and trouble caused by frequent replacement of the filter screen.
(IV) Strong Adaptability
It can adapt to various fluids with different properties, such as water, various industrial oils, chemical solutions, etc., and can work normally under different temperature and pressure environments. It can be widely used in many industries such as chemical industry, power industry, metallurgical industry, food industry, and municipal engineering, meeting diverse filtration needs.
(V) Energy Saving and Environmental Protection
During the cleaning process, by precisely controlling the cleaning time and methods and making rational use of energy, unnecessary energy consumption can be avoided. Meanwhile, maintaining good filtering effect also helps to reduce the energy loss caused by the wear and blockage of downstream equipment due to impurities, achieving the goal of energy saving and environmental protection as a whole.
Application Fields
(I) Chemical Industry
During the chemical production process, raw materials, intermediate products and finished products often contain various impurities during pipeline transportation, such as granular catalysts, unreacted raw material residues, etc. The automatic self-cleaning filter can filter these fluids to prevent impurities from entering subsequent reaction equipment or affecting product quality, ensuring the smooth progress of chemical production and also reducing the potential safety hazards caused by the blockage of pipelines by impurities.
(II) Power Industry
In thermal power generation, the cooling water system needs to be recycled continuously. The impurities such as sediment and algae in the water will affect the cooling effect, and then affect the operation efficiency and service life of the generator set. This filter can filter the cooling water to remove impurities, ensure the normal operation of the cooling system, improve the power generation efficiency and reduce the equipment maintenance cost.
(III) Metallurgical Industry
In the metallurgical production, metal chips, dust and other impurities are easily mixed into rolling oil, emulsion and other substances during the use process. The automatic self-cleaning filter can timely filter these impurities, ensure the cleanliness of the oil, maintain the normal lubrication and cooling effects of equipment such as rolling mills, extend the service life of the equipment and improve the surface quality of products.
(IV) Food Industry
For the transportation of drinking water, process water and various liquid raw materials in food processing, it is necessary to ensure their purity and avoid impurities being mixed into food. This filter can effectively filter impurities and microorganisms in water, ensure that food production meets hygiene standards, guarantee food safety and maintain the good reputation of enterprises.
(V) Municipal Field
In the urban water supply system, the source water may contain impurities such as sediment and rust. The automatic self-cleaning filter can be used as a pre-filtration device to preliminarily purify the raw water, reduce the burden of subsequent water treatment processes and improve the water supply quality. In sewage treatment, it can also be used to filter large particle impurities in sewage to facilitate subsequent in-depth treatment.
Conclusion
The automatic self-cleaning filter demonstrates powerful advantages in fluid filtration with its advanced design concept, reasonable technical parameters, efficient working principle, excellent performance characteristics and wide application fields. It can not only meet the strict requirements of different industries for fluid purity, ensure the smooth progress of production, the quality of products and the normal operation of equipment, but also reduce the use cost and management difficulty of enterprises by virtue of its advantages such as automation, energy saving and environmental protection. With the continuous development of industry and the continuous improvement of people’s requirements for the quality of life, the automatic self-cleaning filter will surely be deeply applied in more fields and continue to contribute to creating a clean and efficient fluid environment.If you are interested or have any questions, please contact us.
