PP filter element is actually one of the water purifier filter element, its main use is a non-toxic and tasteless polypropylene as raw material, after heating melting, injection, traction and receiving forming a series of processing and made of filter material. The pore size of PP filter element is very uniform, the deep filtration structure of thin and dense inside, has high filtration efficiency and acid and alkali resistance, and can effectively remove some impurities such as suspended matter, particles and rust in the liquid.
Technical Parameters
– Filtration accuracy: 1-50μm (support customisation)
– Maximum working temperature: 65℃ (peak 80℃)
– Differential pressure range: ≤0.3MPa
– Certification system: ISO9001
Safe Material
100% virgin polypropylene moulded in one piece by hot melt, eliminating the risk of adhesive precipitation, certified to meet the needs of high hygiene standards for pharmaceuticals and drinking water.
Gradient Filtration
Five-layer progressive pore size design, from the outside to the inside to achieve 20μm → 1μm intelligent graded retention. Compared with the traditional cartridge to enhance the dirt holding capacity of 40%, extend the service life by 3 times.
Resistant to chemical corrosion
Resistant to strong acid and alkali environments, stable performance in extreme scenarios such as electroplating wastewater, chemical material filtration, etc., without the potential danger of fibre shedding.
High-temperature and high-pressure adaptability
80℃ instant temperature resistance and 10Bar pressure capacity, with stainless steel reinforced core option, can cope with boiler water treatment, heat circulation system and other special working conditions.
Modularity
We provide standard specifications from 5-inch portable models to 40-inch high-flow models, and support non-standard customisation to fit all kinds of filter housings.
Full range of applications
From semiconductor ultrapure water preparation to beverage filling lines, from laboratory analytical water to cooling tower recirculation systems, its reliability has been proven in many industrial scenarios around the world.
PP filter element is actually a multi-stage filtration system, which can particularly effectively remove the sediment, bacteria, rust and chemical pollutants in the water quality, decontamination at the same time can also save the nutrients in the water quality, so that the water purifier has played a huge effect. At the same time, it can also be used for vegetable oil, syrup, chocolate and other slurry filtration, industrial water, electroplating liquid filtration and industrial pure water filtration front system, it can be said that the utility of PP filter is very common.
1、PP filter element is a multi-layer depth structure, so its pollution volume is very large, so the service life will be relatively long.
2、The filter flow of PP filter element is very large, and the pressure difference is small.
3、PP filter element can effectively remove all kinds of particles and impurities in the filtrate, and the filtration performance is very strong.
4、PP filter element has acid resistance, alkali, organic solution and oil and other attributes, so its chemical stability performance is very good.
5、PP filter element is not rich in any chemical adhesive, so it is very safe and health care.
6、 the cost of PP filter is cheaper, replacement is also very simple.
Application Scenarios
√ Reverse osmosis equipment pre-protection
√ Purification of metal surface treatment fluids
√ Vaccine production water pre-treatment
√ Data centre cooling water maintenance
√ Desalination pre-treatment system
√ Dairy production line particle control
