Product Introduction
Technical Specifications
(I) Filtration Rate
It is generally around 8 – 15 cubic meters per hour. However, the specific value will be adjusted according to factors such as the types of filter materials, particle sizes and water quality conditions. A reasonable filtration rate can ensure good filtration effect and stable operation.
(II) Working Pressure
The working pressure range it can withstand is mostly between 0.1MPa and 0.6MPa, which can be adapted to the pressure environment of most conventional water treatment pipeline systems to ensure stable filtration under the corresponding pressure.
(III) Filtration Precision
It has a good removal effect on suspended solids and impurities with a particle size larger than 50 micrometers. Different combinations of media can adjust the filtration precision to some extent to meet diverse water treatment needs.
Working Process
After the water containing impurities enters from the top or side of the filter, it will first be evenly distributed over the entire filtration layer. The water flows downward through different media layers in turn. During this process, each medium plays its role according to its own pore structure and adsorption characteristics. For example, quartz sand, with relatively coarse particles, can intercept suspended solids with larger particle sizes; anthracite coal, with relatively more developed pores, can adsorb some fine colloids and impurities; and manganese sand has a special ability to remove metal ions such as iron and manganese in water. As the water continues to flow through, impurities are continuously retained, and finally, clear water flows out from the bottom outlet, achieving water purification.
Product Features
(I) High-Efficiency Filtration
With the synergistic filtration of multiple media, it has a good removal ability for impurities of different particle sizes and properties, can significantly reduce the turbidity of water and improve the purity of water quality, meeting the requirements of various water use scenarios.
(II) Stable Operation
It has a simple and mature structure without complex and easily damaged components. As long as regular maintenance operations such as backwashing of filter materials are carried out, it can operate stably for a long time to ensure the continuous progress of water treatment work.
(III) Low Cost
Compared with some high-end filtration equipment, its structure is relatively simple, the cost of filter materials is not high and they are easy to obtain. Both the equipment procurement cost and the later operation and maintenance costs are relatively reasonable, with outstanding cost performance.
(IV) Wide Adaptability
It can handle various types of raw water, whether it is surface water, groundwater or slightly polluted industrial wastewater. Effective filtration treatment can be carried out by adjusting the combination of filter materials.
Application Fields
(I) Municipal Water Supply
As a pretreatment link, it preliminarily filters the raw water to remove sediment, suspended solids and so on in the water, reducing the burden of subsequent in-depth treatment processes and improving the water supply quality to ensure the safety of residents’ water use.
(II) Industrial Water Use
In many industrial productions, such as the chemical, power, and textile industries, there are requirements for the quality of production water. The multi-media filter can provide water sources that meet the requirements and avoid the impact of impurities in water on production equipment and product quality.
(III) Sewage Treatment
It conducts front-end coarse filtration on sewage to remove large particle impurities, which is conducive to the more efficient development of subsequent biochemical treatment, in-depth treatment and other processes, improving the overall efficiency of sewage treatment.
(IV) Swimming Pool Circulating Water
It filters impurities such as hair, dander and dust in the water to maintain the clarity of the swimming pool water and ensure the health and good user experience of swimmers.
Conclusion
The multi-media filter plays an important role in water purification in many fields with its unique structure, reasonable technical parameters, efficient working principle and excellent performance characteristics. It can not only meet the requirements of different scenarios for water quality, ensure the safety of water use and the normal progress of production, but also is favored because of its cost advantages and simple operation. In the future, it will surely continue to play a role in more relevant fields. If you are interested or have any questions, please contact us.
