PP Melt-Blown Filter: Multi-Layer Shield for Purity in Diverse Flows

Introduction

Fluid impurities—whether rust in pipelines, bacteria in beverages, or particulates in chemicals—pose hidden risks to systems and products. The PP Melt-Blown Filter neutralizes these threats with its outer-loose-inner-dense tri-layer design, trapping contaminants from 1μm upwards. Made of FDA-compliant polypropylene, featuring a needle-punched surface for expanded filtration area, and built to withstand pressure surges, it serves as a critical pre-filter for RO systems, industrial processes, and food-grade applications, ensuring clean, compliant fluid output.

PP Melt-Blown Filter: Multi-Layer Shield for Purity in Diverse Flows

Features

① Gradient Filtration Efficiency

A three-layer structure (loose outer layer → compact middle layer → precise inner layer) traps impurities incrementally:

Outer layer: Captures large particles (sediment, rust) to reduce initial flow resistance.
Middle layer: Intercepts medium-sized contaminants (colloids, organic debris).
Inner layer: Blocks fine particles (down to 1μm) and microorganisms.
This design boosts dirt-holding capacity by 30% vs. single-layer filters, extending service life.

② Food-Grade Safety

Constructed from 100% pure PP, the cartridge meets FDA standards, ensuring no secondary contamination. Ideal for potable water, food, and pharmaceutical applications.

③ Enhanced Pressure Resistance

An inner-threaded structure reinforces mechanical strength, withstanding up to 0.5 MPa differential pressure without deformation—minimizing bypass risks.

④ Needle-Punched Surface

The needle-punched design increases the effective filtration area by 25%, promoting smooth flow and reducing clogging in high-particulate environments.

Technical Data

Parameter	Specification
Material	Polypropylene (PP)
End Cover/Core	Polypropylene
Sealing Options	EPDM, NBR, FKM (customizable)
Sizes	Length: 5”, 10”, 20”, 30”, 40”, 50”, 60” Outer Diameter: 60±1mm Inner Diameter: 28–30mm
Filtration Precision	1μm, 3μm, 5μm, 10μm, 20μm, 30μm, 50μm
Working Pressure	0.1–0.3MPa (max 0.5MPa)
Max Temperature	80°C
Connections	Flat top, 226, 222, custom threads

Working Principle

The PP melt-blown cartridge operates via a gradient porous mechanism:

Fluid Inflow: Contaminated fluid enters the outer loose layer, where large particles (e.g., sediment, rust) are trapped.
Intermediate Filtration: As fluid moves to the compact middle layer, medium-sized impurities (colloids, organic debris) are mechanically intercepted.
Fine Filtration: The precise inner layer blocks fine particles (≥1μm) and microorganisms, ensuring ultra-clean output.

Over time, accumulated contaminants increase the pressure differential across the cartridge—indicating the need for replacement.

Application Field

① Drinking Water Purification

Pre-filtration for RO systems in households and commercial plants, protecting membranes from sediment and turbidity.

② Industrial Fluid Treatment

Filters acidic/alkaline solutions, plating baths, and chemical solvents in petrochemical, metallurgy, and electroplating industries.

③ Food & Beverage

Clarifies juice, beer, and dairy products, ensuring compliance with FDA/HACCP standards.

④ Electronics & Pharmaceuticals

Produces ultra-pure water for semiconductors and injectable drugs, removing particles >1μm.

⑤ Wastewater Recycling

Treats industrial wastewater (printing ink, tannery effluent) for reuse or discharge compliance.

Q&A

Q1: How often should I replace the filter?

A: Replace when the pressure differential reaches 0.2MPa or after 3–6 months of continuous use (varies by fluid quality). Monitor pressure gauges for timely changes.

Q2: Can it filter bacteria and viruses?

A: Yes! A 1μm precision cartridge blocks most bacteria (e.g., E. coli, 1–5μm) and protozoa. For viruses (<0.1μm), pair with RO or UV disinfection.

Q3: Is the material safe for drinking water?

A: Absolutely. The PP material is FDA-approved, non-toxic, and chemically inert—no leaching into potable water.

Q4: Can I customize the filter?

A: Yes! We offer custom lengths (5”–60”), precision (1–50μm), and connection types (e.g., 226, 222 threads) to match your system.

Q5: What’s the maximum operating temperature?

A: The cartridge handles up to 80°C. For higher temperatures, contact us for heat-resistant material options.

If you are interested in this product or have any questions, please feel free to contact us at any time.
