A new micro-irrigation system has been built in a farm. Micro-irrigation is an advanced water-saving irrigation technology, which can provide the required amount of water to the water-demanding parts of the crops, and convert from “watering the ground” to “watering the crops”.
Micro-irrigation is used in facility agriculture and cash crops, with water-saving and yield-enhancing effect, even irrigation, at least 50% water saving than sprinkler irrigation, irrigation water consumption from 20,000 tons/hour effectively reduced to 10,000 tons/hour, and water-fertilizer integration.
Project Problems
Micro-irrigation on the water quality and daily system maintenance requirements are high, because the irrigation water contains a lot of gravel and other particles in the raw water impurities, the site often appears during the use of pipeline and sprinkler nozzle clogging, so the need for impurities in the raw water filtration and removal, according to the site requirements, Lifelite to do the following specific program design:
Project design parameters
Product selection: Brush-type self-cleaning filter (right-angle type)
Processing capacity: 10000T/h
Equipment material: carbon steel shell, brush/strainer 304
Working pressure: 0.6MPA
Filtration precision: 120 mesh
Control mode: differential pressure/timed automatic backwashing and drainage
Equipment selection: LFZ-530-250, 15 sets; LFZ-600-300, 6 sets
Working Principle
When water enters the inside of the filter cartridge from the inlet, the impurities are intercepted in the inner wall of the cartridge, and the clean water after filtration flows out from the outlet; when there are more impurities in the inner wall of the cartridge, and the pressure difference between the filter inlet and outlet reaches a preset value or reaches the cleaning time, the filter will start self-cleaning.
Product design features
✔ Quickly enter the operation mode
✔Adopt automatic control technology to ensure reliable operation of the equipment
✔ No concrete foundation, reduce labor cost
✔Flexible selection of materials for different working conditions
✔Applicable to multiple water, high working efficiency
✔The whole machine adopts automatic control, each parameter is easy to adjust, can realize unmanned work
