High speed submersible mixer and agitators are able to be located at any position. They have the best efficiency. They are widely used in waste water treatment plants and industry process to agitate the suspended substances contained water, watery slurry, icy water, liquid from industry process, roast liquid, etc. They can be also used to create water flow in the tank, to open up water channel, to oxygenate fishing pound, to prevent pound form icing.
High-speed submersible mixer, as the equipment in the wastewater treatment process, is widely used in various industrial and municipal sewage treatment plants. It is a processing equipment for mixing and pushing of solid-liquid two phase or solid-liquid-gas three phase before biochemical treatment.
Working principle:
High-speed submersible agitator is mainly used in municipal and various industrial sewage treatment projects in mixing, mixing and circulation. It can also be used for landscape waterscape maintenance. The impeller rotation movement can create the role of water flow, improve the quality of water, increase the oxygen content of water, effectively prevent the deposition of suspended matter.
Features:
1.Compact structure,small volume,light weight, easy operation maintenance,fast installation,long service life etc.
2.The blade has the self-cleaning function, can prevent sundries wind,blocking
3.Can combine with aeration system to make energy reduced greatly, greatly increase oxygen volume, effective prevent sediment.
4.Motor winding is F grade insulation, protection grade is IP68.
5.All fastener is stainless steel.
Condition of Application:
1. The temperature of the stirring medium is generally 0°C-40°C;
2. The scope of PH value of the medium: 5-9;
3. The density of the medium shall not exceed 1150Kg/m 3;
4. The depth of submersion shall not exceed 20m.
Equipment Selection:
For the purpose of fulfilling the optimum mixing function in different environment, we can supply multiple types of the submersible mixers to the uers and provide type selection service as well. Please provide the following reference conditions:
1. Mixer application environment, such as sewage tank, slag pond or biochemical pond.
2. The parameters of the medium such as content of the suspended substances, temperature, pH value etc…
3. The shape of the pond, water depth and the mode of installation. Meanwhile, it is also necessary to cansider the energy-saving factor, because this will influence the operating cost of the user in the future.
Note: In line with the requirement of the special environment, our company can provide special design for the users.
The supporting power required by the mixer is determined according to the volume size, the density, viscosity and mixing depth of the mixing liquid, and one or more mixer should be used according to the specific situation. Please contact us, for the selection questions.
